Categories
Assembly tools
QE2PT010P10Q04 Torque wrench 2-10 Nm
Electric torque wrench compatible with IC Insight controllers
Torque: 3–15 Nm
Speed: 560 rpm
Ultra-lightweight: 0.95 kg
Length: 318 mm
Activated by pressing the lever
QE2AL015PA3Q04 Lever-operated angle wrench 3-15 Nm
Trigger-activated with simultaneous pressure
Range: 0.3 - 5.4 Nm.
Speed: 500 rpm.
Weight: 0.7 kg.
Length: 241 mm.
Output: 1/4" QC.
Clutch type: adjustable slip clutch
QS1T05C1D Straight pneumatic screwdriver 0.3-5.4 Nm
Electric straight wrench compatible with IC Insight controllers
Torque: 3 - 12 Nm
Speed: 1220 rpm
Ultra-lightweight: weight 1.2 kg
Length 340 mm
QE4TS015R11S06 Straight torque wrench, 3-12 Nm
Lever-operated
Range: 50 - 165 Nm.
Speed: 150 rpm.
Weight: 3.2 kg.
Length: 472 mm.
Output: 1/2".
Clutch type: precision adjustable disengagement clutch
BALD4202RD5-R50-S8 Angled pneumatic screwdriver 50-165 Nm
Push-button operated
Range: 0 - 2.9 Nm.
Speed: 2000 rpm.
Weight: 0.68 kg.
Length: 162 mm.
Output: 1/4".
Clutch type: direct drive
QP1S20D1TD Pneumatic pistol-grip screwdriver 0-2.9 Nm
The spindle features increased durability.
Range: 163 - 516 Nm
Weight: 18.7 kg
Length: 711 mm
Output: 1"
Spindle length: 150 mm
Deflection: 50 mm
QM9SS650H62S16 Electric built-in torque wrench 163-516 Nm
Push-button start
Range: 2.3 - 12.5 Nm.
Speed: 1000 rpm.
Weight: 1.5 kg.
Length: 268 mm.
Output: 1/4" QC.
Clutch type: adjustable slip clutch
7RAMC1-EU Pistol-grip pneumatic screwdriver 2.3-12.5 Nm
The ICS Enterprise package enables advanced programming and network management of a group comprising up to 500 IC1D or IC1M controllers that control QE tools, QM spindles, or multi-spindle systems. It also enables archiving in an ODBC-compliant database, as well as searching and statistical processing.
License for 20 workstations.
ICS-Enterprise-020 - Software for IC12D / IC12M controllers
ICS Network enables the programming of multiple IC1D and IC1M controllers connected to each other via an internal computer network (LAN) or directly. This option also allows operators to program advanced fastening strategies, including control of plastic deformation and peak tightening torque.
License for 1 workstation.
ICS-Network-001 - Software for IC12D / IC12M controllers
QE4AT020PA2S06 Angle wrench 4-16 Nm
The spindle features increased durability.
Range: 14 - 44 Nm
Weight: 3.9 kg
Length: 523 mm
Output: 1/2"
Spindle length: 150 mm
Deflection: 50 mm
QM5SS055H62S08 Electric built-in torque wrench 14-44 Nm
Lever-operated
Range: 35 - 70 Nm.
Speed: 320 rpm.
Weight: 2.45 kg.
Length: 445 mm.
Output: 1/2".
Clutch type: precision adjustable disengagement clutch
QA8AALS070BP43S08 Angled pneumatic screwdriver 35-70 Nm
VersaTec electric impact driver with pressure activation.
Range: 2 - 4.5 Nm,
Power supply: 230 V (transformerless),
Speed: 400 rpm,
Weight: 0.73 kg,
Length: 286 mm,
Output: 1/4" QC
EP4004E VersaTec Electric Screwdriver 2-4.5 Nm
Push-button activation
Range: 1.7–9 Nm.
Speed: 1000 rpm.
Weight: 1.4 kg.
Length: 239 mm.
Output: 1/4" QC.
Clutch type: adjustable slip clutch
41PC10TSQ4-EU Pistol-grip pneumatic screwdriver 1.7-9 Nm
The ICS MultiSync package facilitates the configuration and control of multi-spindle systems consisting of up to 100 spindles divided into groups of up to 40. This package also offers multi-spindle clamping strategies, remote monitoring, and data archiving.
License for 5 workstations.
ICS-Multisync-005 - Software for IC12D / IC12M controllers
Lever-operated
Range: 125 - 225 Nm.
Speed: 90 rpm.
Weight: 4.02 kg.
Length: 508 mm.
Output: 3/4".
Clutch type: precision-adjustable release clutch
QA8AALS225BF56S12 Angled pneumatic screwdriver 125-225 Nm
QE8AT150PA6S08 Angle wrench 30-120 Nm
Push-button operated
Range: 1 - 2.5 Nm.
Speed: 1700 rpm.
Weight: 1 kg.
Length: 220 mm.
Output: 1/4" QC.
Clutch type: precision adjustable shut-off clutch
LD1214RP5-Q4 Pistol-grip pneumatic screwdriver 1-2.5 Nm
Electric straight wrench compatible with IC Insight controllers
Torque: 4-16 Nm
Speed: 1840 rpm
Weight: 2.1 kg
Length: 500 mm
QE6ST020F41S06 Push-button open-end wrench 4-16 Nm
Lever-operated
Range: 2.6 - 9.4 Nm.
Speed: 140 rpm.
Weight: 1 kg.
Length: 287 mm.
Output: 3/8".
Clutch type: precision adjustable slip clutch
BALD1202RD5-R25-S6 Angled pneumatic screwdriver 2.6-9.4 Nm
Trigger and pressure-activated
Range: 0.3 - 3.1 Nm.
Speed: 2000 rpm.
Weight: 0.7 kg.
Length: 241 mm.
Output: 1/4" QC.
Clutch type: adjustable slip clutch
QS1T20C1D Straight pneumatic screwdriver 0.3-3.1 Nm
The spindle features increased durability.
Range: 2 - 6 Nm
Weight: 2.4 kg
Length: 449 mm
Output: 3/8"
Spindle length: 150 mm
Deflection: 50 mm
QM3SS008H62S06 Electric built-in torque wrench 2-6 Nm
Lever-operated
Range: 75 - 150 Nm.
Speed: 145 rpm.
Weight: 3.12 kg.
Length: 489 mm.
Output: 1/2".
Clutch type: precision adjustable disengagement clutch
QA8AALS150BP48S08 75-150 Nm angle pneumatic screwdriver
Push-button operated
Range: 2.1 - 5.7 Nm.
Speed: 1000 rpm.
Weight: 1.2 kg.
Length: 231 mm.
Output: 1/4" QC.
Clutch type: precision adjustable shut-off clutch
LD2210RP5-Q4 Pistol-grip pneumatic screwdriver 2.1-5.7 Nm
Pressure-activated
Range: 1.7 - 11.3 Nm.
Speed: 800 rpm.
Weight: 1.2 kg.
Length: 277 mm.
Output: 1/4" QC.
Clutch type: precision adjustable release clutch
41SA8PSQ4-EU Straight pneumatic screwdriver 1.7-11.3 Nm
VersaTec push-button electric screwdriver.
Torque range: 0.6–1.7 Nm,
Power supply: 34 V DC (with EC34-ES power supply),
Speed: 1200 rpm,
Weight: 0.68 kg,
Length: 286 mm,
Output: 1/4" QC
EP1512S VersaTec Electric Screwdriver 0.6-1.7 Nm
Thanks to features such as a color VGA display and an intuitive programming interface, IC1D controllers deliver performance and added value unmatched by other controllers. The device is compatible with all tools and spindles in the QE/QM series
IC12D3A1AWS Controller with VGA display and keyboard
Lever-operated
Range: 20 - 40 Nm.
Speed: 450 rpm.
Weight: 2.3 kg.
Length: 478 mm.
Output: 3/8".
Clutch type: precision adjustable shut-off clutch
QA6ASLS040BP41S06 Straight pneumatic screwdriver 20-40 Nm
Lever-operated
Range: 0.3 - 3.4 Nm.
Speed: 1000 rpm.
Weight: 0.5 kg.
Length: 222 mm.
Output: 1/4".
Clutch type: precision adjustable shut-off clutch
1RLNS1 Straight pneumatic screwdriver 0.3-3.4 Nm
Lever-operated
Range: 0 - 6.8 Nm.
Speed: 850 rpm.
Weight: 0.7 kg.
Length: 227 mm.
Output: 1/4".
Clutch type: direct drive
QA1L08D4LD Angled pneumatic screwdriver 0-6.8 Nm
Activated by pressing the button and simultaneously pressing down
Range: 0.3 - 6.5 Nm.
Speed: 500 rpm.
Weight: 0.84 kg.
Length: 223 mm.
Output: 1/4".
Clutch type: precision adjustable shut-off clutch
QP1T05S1TD Pneumatic pistol-grip screwdriver 0.3-6.5 Nm
QE6AT040PA4S06 Angle wrench 8-32 Nm
Trigger-activated and pressure-activated
Range: 0.3 - 4.5 Nm.
Speed: 1000 rpm.
Weight: 0.84 kg.
Length: 223 mm.
Output: 1/4".
Clutch type: precision adjustable shut-off clutch
QP1T10S1TD Pistol-grip pneumatic screwdriver 0.3-4.5 Nm
The spindle features increased durability.
Torque range: 55 - 176 Nm
Weight: 8.6 kg
Length: 720 mm
Output: 3/4"
Spindle length: 225 mm
Deflection: 50 mm
QM7SS220H92S12 Electric impact wrench 55-176 Nm
Electric angle wrench designed for installation
Torque: 30–120 Nm.
The spindle features increased durability.
Speed: 510 rpm
Weight: 2.9 kg
Length: 515 mm
QE8AC150FA6S08 Built-in angle wrench 30-120 Nm
Lever-operated
Range: 12 - 25 Nm.
Speed: 720 rpm.
Weight: 2.3 kg.
Length: 478 mm.
Output: 3/8".
Clutch type: precision adjustable shut-off clutch
QA6ASLS025BP41S06 Straight pneumatic screwdriver 12-25 Nm
Lever-operated
Range: 0.4 - 5.2 Nm.
Speed: 700 rpm.
Weight: 0.79 kg.
Length: 318 mm.
Output: 1/4".
Clutch type: precision-adjustable release clutch
1RLN2S5 Angled pneumatic screwdriver 0.4-5.2 Nm
Push-button start
Range: 0 - 5.1 Nm.
Speed: 2500 rpm.
Weight: 1 kg.
Length: 183 mm.
Output: 1/4" QC.
Clutch type: paw clutch
41PP25TSQ4-EU Pistol-grip pneumatic screwdriver 0-5.1 Nm
Lever-operated
Range: 0–111.5 Nm.
Speed: 300 rpm.
Weight: 3.5 kg.
Length: 454 mm.
Output: 1/2".
Clutch type: direct drive
9RSQ83-EU Angled pneumatic screwdriver 0-111.5 Nm
Push-button operated
Range: 0 - 5.2 Nm.
Speed: 1000 rpm.
Weight: 0.68 kg.
Length: 162 mm.
Output: 1/4".
Clutch type: direct drive
QP1S10D1TD Pistol-grip pneumatic screwdriver 0-5.2 Nm
Pressure-activated
Range: 1.6 - 10 Nm.
Speed: 180 rpm.
Weight: 0.8 kg.
Length: 243 mm.
Output: 1/4".
Clutch type: precision adjustable shut-off clutch
LD1202RD3-Q4 Straight pneumatic screwdriver 1.6-10 Nm
Electric straight wrench compatible with IC Insight controllers
Torque: 30-120 Nm
Speed: 500 rpm
Weight: 3 kg
Length: 557 mm
QE8ST150F41S08 Push-button open-end wrench 30-120 Nm
Electric straight wrench compatible with IC Insight controllers
Torque: 1.3 - 6.5 Nm
Speed: 1250 rpm
Ultra-lightweight: weight 0.57 kg
Length 250 mm
QE2TS007P11Q04 Straight torque wrench, 1.3-6.5 Nm
Lever-operated
Range: 25 - 55 Nm.
Speed: 325 rpm.
Weight: 2.31 kg.
Length: 478 mm.
Output: 1/2".
Clutch type: precision adjustable disengagement clutch
